BECKHOFF EL2809 EtherCAT 16-Channel Digital Output Module

  • BECKHOFF EL2809 EtherCAT 16-Channel Digital Output Module
Place of Origin GERMANY
Brand Name BECKHOFF
Certification CO
Model Number EL2809
Minimum Order Quantity 1pc
Packaging Details BRAND NEW WITH FACTORY PACKAGE
Delivery Time 2-3 days
Payment Terms T/T
Supply Ability 100PCS PER WEEK

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
PART NO. EL2809 Weight 0.2 KG
Actual Price Negotiabled Condition New Original With Sealed
Application Oil And Gas Factory Color Normal
High Light

EtherCAT Digital Output Module

,

EL2809 Digital Output Module

,

16Channel Digital Output Module
Leave a Message
Product Description

BECKHOFF EL2809 EtherCAT 16-Channel Digital Output Module





Description



 Model

EL2809

Brand/Manufacturer

Beckhoff

DataSheet/Catalogue

In PDF File

Weight/Dimension

12 mm x 100 mm x 68 mm

Condition

Brand new

Description
EtherCAT Terminal, 16-channel digital output, 24 V DC, 0.5 A





Technical Data



The EL2809 digital output terminal connects the binary 24 V DC control signals from the automation device on to the actuators at the process level with electrical isolation. The EtherCAT Terminal has 16 channels, whose signal states are indicated by LEDs. The power contacts are connected through. The connection technology is particularly suitable for single-ended inputs. All components have to use the same reference point as the EL2809. In the EL2809 the outputs are supplied via the 24 V DC power contact.

Special features:

Connection of different load types possible (ohmic, inductive, lamp load)
Max. output current 0.5 A per channel
Overload and short-circuit proof outputs and reverse polarity protection
Tool-free connection by direct plug-in technology for solid wire conductors
Space-saving use in the control cabinet
Direct connection of multi-channel actuators in 1-wire connection technology in the smallest space
Increased packing density with 16 connection points in the housing of a 12 mm terminal block
